Galvanic isolation between the stabilizer and the main power supply
Change the voltage grade
Improve the balance of the phase voltage and provide a steady neutral point.
Protection from voltage surge and cancel the triplen harmonics.

Capacity
 1KVA-3000KVA
Voltage Grade
 <= AC1140V
Input Voltage range
 According to order
Output Voltage
 According to order
Vector group
 Dyn11,Dzn0 or else according to order
K rate
 K4,K12,K20  or else according to order
Frequency
 50Hz or 60Hz
Dielectric Strength
 3500V / 10mA / 60s
Loading capability When the transformer is 100% loaded, it can take 3 times current in short time.
Insulation ≥100MΩ ( DC 500V )
Insulation Grade F
Working Temperature
 —15°C--+45°C
Humidity
 ＜95℅
Temperature increase
 ＜100K
Noise
 ＜55db
